| SPECIFICATIONS |
| Video Input | 4 Channel input |
| Split Display Mode | 1, 4 |
| Multiplex Mode | Quadruplex (Live/Record/Playback/Ethernet) |
| Display Resolution (BNC) | 720 x 480 (NTSC) / 720 x 576 (PAL) |
| Display Resolution (VGA/DVI) | 1280 x 1024 (quad) |
| Color | 16 million |
| Compression Algorithm | H.264 enhanced |
| Display Rate | 120 fps (NTSC) / 100 fps (PAL) |
| Recording Rate | Max 60 fps (NTSC) / 50 fps (PAL) |
| Recording Resolution | 640 x 480 (NTSC) / 640 x 512 (PAL) |
| Network Connection | TCP/IP, PPPoE, DDNS |
| Record Quality | 5 levels |
| Max Compression Rate | 300:1 |
| Motion Recording | Yes |
| Playback Mode | File / Event / Date & Time / Frame Search |
| Motion Detection | 12 (4x3) motion zones |
| Alarm Function | 4 input / 1 output |
| Backup | CF card or Hard Drive |
| Storage | 120GB ~ 500 GB SATA (not included) |
| BNC Input | 4 |
| BNC Output | 1 |
| Audio Input | RAC x 2 |
| Audio Output | RCA (L,R) |
| Power Supply | DC12V / 100~240V |
| Dimension | 426 (W) x 328.5 (D) x 73 (H) mm |
| Operating Temp | 5 deg. C ~ 40 deg. C |
| Operating Humidity | 10-75% |
