| SPECIFICATIONS |
| Video I/F | NTSC/PAL Auto Detect |
| Video Input | 4 Channel input 1.0Vp-p, 75ohm unbalanced (BNC type) |
| Video Output | main-monitor composite (BNC type) x 1 |
| Horizontal Resolution | 640 x 448 (NTSC) / 640 x 544 (PAL) |
| S/N Ratio | More than 40dB |
| Color | 16.7 million |
| Screen Quality | Full: 640 x 448 active pixels (NTSC) / 640 x 544 active pixels (PAL)
Quad Screen: 320 x 224 active pixels (NTSC) / 320 x 272 active pixels (PAL) |
| Display Rate | 120 fps (NTSC) / 100 fps (PAL) |
| Recording Rate | Max 60 fps (NTSC) / 50 fps (PAL) |
| Recording Resolution | 640 x 224 (NTSC) / 640 x 272 (PAL) |
| Adjustable Recording Speed | 60 ~ 0 fps (NTSC); Max 50 ~ 0 fps (PAL) |
| Record Quality | High, normal, low |
| Compress Method | Storage: MJPEG, Network/internet: MPEG4 |
| Recording Control | Auto / Manual / Schedule / Motion / Alarm |
| Playback Mode | Time List / Event List / Date & Time Search |
| Motion Detection | 16 x 16 grids camera for all channel |
| Alarm Function | 4 input / 1 output |
| Backup | USB1.1/2.0 memory and network remote backup |
| Storage | SATA HDD x 2 (max 1T) |
| Audio Input | RAC x 1 |
| Audio Output | RAC x 1 |
| Web Interface | Support licensed software AP |
| Network Connection | TCP/IP, PPPoE, DHCP, DDNS |
| Power Supply | DC12V / 5A |
| Dimension | 426 (W) x 328.5 (D) x 73 (H) mm |
| Operating Temp | 41 deg. F ~ 104 deg. F (5 deg. C ~ 40 deg. C) |
| Operating Humidity | Less than 90% |
